光宝科技提供固瑞克finex重力式空气喷枪

来源:gounbot     2019年01月12日 16:01



finex空气喷枪

轻型、符合人体工程学的空气喷枪

实惠的压力和重力自动加料枪用于修补作业或大型作业

finex喷枪匀称轻巧,是一种更加实惠的喷涂选择;提供压力加料或重力加料喷枪选件,以及hvlp或常规技术。


功能:


1.喷嘴经过优化,可实现高质量的喷涂效果
2.轻型、符合人体工程学的喷枪
3.同类中最轻的扳机引力
4.一体式风门调节
5.提供多种针/喷嘴大小以供选择


规格:

finex gravity feed airspray guns
maximum air inlet pressure
7.0 bar, 0.7 mpa
maximum fluid working pressure
7.0 bar, 0.7 mpa
maximum hvlp inbound air pressure
2.0 bar, 0.2 mpa
fluid and air operating temperature range
0–43°c
air inlet
1/4 npsm (r1/4–19)
wetted parts
aluminum, stainless steel, engineered plastic
gravity cup size
mini hvlp gravity feed spray guns
125 cc
standard conventional and hvlp gravity feed spray guns
600 cc
weight
mini hvlp gravity feed gun, with cup
0.4 kg
standard gravity feed gun, with cup
0.5 kg
air consumption
mini hvlp gravity feed spray guns at 29 psi (2.0 bar, 0.2 mpa)
0.20 m³/min
conventional gravity feed spray guns at 43 psi (3.0 bar, 0.3 mpa)
0.27 m³/min
hvlp gravity feed spray guns at 29 psi (2.0 bar, 0.2 mpa)
0.27 m³/min
noise data
mini hvlp gravity feed spray guns
sound power at 29 psi (2.0 bar, 0.2 mpa)
85.32 db(a)
sound pressure at 29 psi (2.0 bar, 0.2 mpa)
78.17 db(a)
conventional gravity feed spray guns
sound power at 43 psi (3.0 bar, 0.3 mpa)
89.23 db(a)
sound pressure at 43 psi (3.0 bar, 0.3 mpa)
81.91 db(a)
hvlp gravity feed spray guns
sound power at 29 psi (2.0 bar, 0.2 mpa)
87.74 db(a)
sound pressure at 29 psi (2.0 bar, 0.2 mpa)
80.60 db(a)
