| pgm | |
| volume repeatability |
+/- 1%
|
| minimum flow rate |
6 cc/rev model: 30 cc/min, 20 cc/rev model: 40 cc/min
|
| maximum flow rate |
6 cc/rev model: 8 cc, 20 cc/rev model: 10 cc
|
| maximum fluid working inlet pressure |
10.3 mpa/103 bar
|
| maximum fluid working outlet pressure |
17.2 mpa/172 bar
|
| air supply pressure range |
60–100 psi (filtration required)
|
| fluid filtration required |
up to 200 mesh, depending on viscosity
|
| viscosity range of fluids |
1,000 — 1,000,000 poise
|
| wetted parts |
stainless steel, tool steel, chrome, carbide, acetal plastic, ptfe, chemical resistant o-rings
|
| power requirements |
full load: 18.5a, fuse rating: 21a
|
| power supply voltage range |
240vac, 50–60 hz, single phase
|
| sound pressure level at maximum flow rate |
6 cc/rev model: 58 db(a), 20 cc/rev model: 72 db(a)
|
| sound power level at maximum flow rate |
6 cc/rev model: 68 db(a), 20 cc/rev model: 79 db(a)
|
| operating humidity range |
10 – 90% non-condensing
|
| overall dimensions | |
| 6 cc/rev model |
50.17 h x 23.83 w x 16.76 d mm
|
| 20 cc/rev model |
55.25 h x 24.13 w x 22.6 d mm
|
| controls |
76.2 h x 60.96 w x 30.48 d mm
|
| weight | |
| 6 cc/revmodel |
13.61 kg
|
| 20 cc/rev model |
27.22 kg
|
| controls |
45.36 kg
|
| operating temperature range | |
| control |
4 to 40 °c
|
| heated pump |
4 to 204 °c
|
| ambient pump |
4 to 49 °c
|
pgm 计量系统
借助卓越的胶型控制和大流量提高生产率
固瑞克 pgm 计量系统可实现高粘度材料平滑、稳定的线状或带状胶型涂布。大流量精确计量分配意味着可实现生产率与运营投资回报率的明显提高。
完美应用于：
• 太阳能板制造
• 汽车挡风玻璃制造
材料包括：
• 常温、温胶型或热熔胶型材料（温度可达400 ºf(204 ºc)）
• 低粘度至高粘度材料
• 流量范围无限制
pgm 的大流量使生产力得到提高
-
高流量：
- 室温材料，高达 600 cc/min
- 高粘度热熔材料，高达 300 cc/min
- 可实现大流量下平滑、稳定的线状或带状胶型涂布
- 启停准确，可减少材料浪费
- 胶型控制可节省材料成本
- 可安装在自动机机械手装置末端，确保极高的分配精度
- 触摸屏控制装置便于操作、整合
规格：
