exactablend agp
固瑞克 exactablend™ agp（高端双组份玻璃胶涂胶设备）可在玻璃幕墙、中空玻璃及其他应用中实现按比例分配双组份密封剂和粘合剂。变比 exactablend agp 以适中的价格提供先进的技术。
功能：
面向玻璃行业的卓越混合和配比保证
- 操作简单
- 绿色指示灯表示正在按比例分配材料
- 在偏离设定比例时自动关闭
- 混合与配比功能，确保优异质量
- 排胶快速而简便，减少材料浪费
- 数据下载功能供选，提供有关配比、流量和材料使用情况的报告
规格：
| exactablend agp advanced glazing proportioner | |
| maximum fluid working pressure : md2 or ultra-lite with flexible hose mixer installed |
21 mpa, 207 bar
|
| maximum fluid working pressure :ultra-lite with tri-core mixer installed |
28 mpa, 276 bar
|
| incoming air pressure required: startup pressures and displacement per cycle may vary based on suction condition, discharge head, air pressure, and fluid type. |
0.6-0.7 mpa, 6.0-7.0 bar
|
| maximum operating temperature |
50°c
|
| voltage range |
90-264 vac 50/60 hz 1 phase
|
| maximum amperage |
4
|
| sound pressure: sound pressure measured 3.3 feet (1 meter) from equipment. |
82 db(a)
|
| wetted parts: refer to specific component manual for more details. |
zinc-plated carbon steel, aluminum ram plate, nitrile rubber wipers, chrome, stainless steel, uhmw polyethylene, ptfe, nylon, buna-n
|
| inlet/outlet sizes | |
| fluid outlet base |
1/2 npt (f)
|
| fluid outlet catalyst |
1/4 npt (f)
|
| air inlet size |
3/4 npt (f)
|
| weight | |
| all models |
392 kg
|
