ultra-lite 6000
操作简便的 ultra-lite 6000 将人机工程学设计与高工作压力结合，来分配中低粘度的工业、汽车行业密封胶与粘合剂。
功能：
- 工作压力达 6000 psi (414 bar; 41.4 mpa)
- 150° 头部/手柄角，操作舒适
- 喷嘴可更换，以满足于各种分配需求
- 轻巧，扳机力小
| ultra-lite pistol grip flo-gun | |
| maximum working pressure | |
| models 235627, 237607, and 237649 |
280 bar
|
| models 235628 and 243775 |
415 bar
|
| outlet port size | |
| all models |
1/4 npt(f) with nut for metal flanged nozzle
|
| inlet port size | |
| models 235627 and 237607 |
1/4 npt(f)
|
| models 235628 and 243775 |
1/2 npt(f)
|
| model 237649 |
37 sae, 1/2-20 unf(m)
|
| valve orifice | |
| models 235627, 237607, 243775, and 237649 |
5.08 mm diameter with tapered needle
|
| model 235628 |
4.83 mm diameter with 6.35 mm carbide ball
|
| height | |
| all models |
149.86 mm
|
| width | |
| all models |
30.48 mm
|
| length | |
| models 235627, 235628, 243775 and 237607 |
204.47 mm
|
| model 237649 |
226.06 mm
|
| weight | |
| model 235627 |
439 g
|
| model 235628 and 243775 |
636 g
|
| model 237607 |
439 g
|
| model 237649 |
483 g
|
| wetted parts | |
| model 235627 |
|
| fluid section |
aluminum
|
| fluid tube |
300 series stainless steel
|
| valve needle |
17-4 ph stainless steel
|
| valve seat |
17-4 ph stainless steel
|
| other |
316 stainless steel, fluoroelastomer, and polyurethane
|
| model 235628 |
|
| fluid section |
17–4 ph stainless steel
|
| fluid tube |
300 series stainless steel
|
| valve needle |
carbide and 17–4 ph stainless steel
|
| valve seat |
carbide and 17–4 ph stainless steel
|
| other |
stainless steel, fluoroelastomer, ptfe; cv75, and polyurethane
|
| model 243775 |
|
| fluid section |
17–4 ph stainless steel
|
| fluid tube |
300 series stainless steel
|
| valve needle |
carbide and 17–4 ph stainless steel
|
| valve seat |
carbide and 17–4 ph stainless steel
|
| other |
stainless steel, fluoroelastomer, ptfe, and polyurethane
|
| model 237607 |
|
| fluid section |
aluminum
|
| fluid tube |
300 series stainless steel
|
| valve needle |
carbide and 17–4 ph stainless steel
|
| valve seat |
carbide and 17–4 ph stainless steel
|
| other |
316 stainless steel, fluoroelastomer, and polyurethane
|
| model 237649 |
|
| fluid section |
aluminum
|
| fluid tube |
300 series stainless steel
|
| valve needle |
carbide and 17-4 ph stainless steel
|
| valve seat |
carbide and 17-4 ph 300 series stainless steel
|
| swivel inlet fitting |
303 stainless steel, and ultra high molecular weight polyethylene
|
| other |
316 stainless steel, fluoroelastomer, and polyurethane
|
