graco在线流体喷枪
可处理：
- 含有玻璃或塑料填料的 pvc 密封胶
- 低至高研磨性流体
- 水性材料或溶剂型涂料
- 大部分流体，粘度可达 150,000 厘泊
功能：
- 尤其适合在水平表面上分配材料
- 板机锁和吊架槽供选，更方便操作
- 法兰连接或螺纹连接喷嘴供选，满足各种分配需求
- 204355 坚固轻便
- 240199 相比同类产品所需触发力更小，重量也更轻
| ultra-lite in-line flow gun | |
| maximum working pressure |
23.4 mpa, 234 bar
|
| maximum temperature |
49°c
|
| flow rate at 2000 psi (14 mpa, 138 bar)* |
4.5 kg/min
|
| model 240–200: 154 oz/min |
4.4 kg/min
|
| outlet port size |
1/4 npt(f) and flange
|
| inlet port size |
1/4 npt(f)
|
| dry weight |
325 gm
|
| model 240–200: 11.6 oz |
325 gm
|
| length |
15.0 cm
|
| width |
6.6 cm
|
| thickness |
2.16 cm
|
| pressure vessel material |
aluminum
|
| pressure vessel id |
6.4 mm
|
| gun seat diameter |
3.2 mm
|
| model 240–200: 0.203 in |
5.2 mm
|
| needle seat type |
model 240–199: carbide ball
|
| model 240–200: 7 tapered carbide | |
| inlet/outlet angle |
20°
|
| trigger force – breakaway @ 1000 psi (7 mpa, 69 bar) |
0.73 kg
|
| model 240–200: 3.8 lb |
1.72 kg
|
| trigger force – breakaway @ 2000 psi (14 mpa, 138 bar) |
1.0 kg
|
| model 240–200: 7.3 lb |
3.31 kg
|
| trigger force – sustaining |
1.45 kg
|
| model 240–200: 2.8 lb |
1.27 kg
|
| wetted parts |
aluminum, stainless steel, carbide, polyethylene, cv75
|
| cv75 is a registered trademark of the international seal co., inc. | |
| * flow rates were measured using pvc sealer dispensed through a 1/8 in. diameter orifice nozzle and z-swivel connected to inlet. actual flow rates will vary depending on material type, fluid pressure, nozzle size, and system configuration. | |
